Freezer Room

Ahata Industries, a renowned manufacturer and supplier in Delhi, has launched a state-of-the-art 8X8X8 freezer room for Corona Vaccine storage at home. With the Covid-19 pandemic raging across the world, the need for efficient and reliable vaccine storage has never been greater. Ahata Industries' freezer room is the perfect solution for households looking to store the Corona vaccine safely and securely. This freezer room comes equipped with advanced features such as temperature control, automated defrost, and high-efficiency compressors. It also has a sturdy construction and is built to last. The product is a testament to Ahata Industries' commitment to innovation and quality, and it is sure to be a game-changer in the fight against Covid-19.

Freezer Room for vaccine with stand by Machine

Internal Freezer R. size LXWXH) : 8ft x 8ft x 8ft – 1 No.s

Product                         : -18 Deg. C. to -20 Deg. C.

Ambient Temp.                 : +45 Deg. C.

Product Incoming Temp.                 : -5 Deg. C.

Pull Down Time                 : 18 to 24 Hrs.

Product                         : Frozen Foods, Ice Cream etc.

Storage Capacity                         : At Actual

Prefab Panels                      : PPGI Sheet on both side with Cam Lock Panel

PUF Panels Make                         : Ahata Make

Insulation Material                 : PUf 40 +/-2 kg per m3

Freezer Puf panel Thickness         : 120mm (wall, Ceiling)

Freezer Flooring Finish         : 120mm Puf slabs with bitumen sheet.

                                (PCC & kota in customer scope)

Insulated Door Quantity         : 1 Nos.

Door Size                         : 900mm x 1800mm (H)

Door Type                         : Swinging Type Hinged Door

Door Leaf Thickness FR & AR         : 120mm & 60mm resp. (PPGI Finish Both side)

Ref. Unit Model No                 : AFR06

No. of Units                         : 2 Nos.

Ref. Unit Make                 : Ahata Make

Ref. Type                         : Split Type

Ref. Load @-25 Deg. Evap. Temp.         :            6,000 BTUs/Hr per unit, 12,000 BTUs/Hrper Chamber

Ref. Load in Kw                 : 3kw.

Compressor Make                 : Emerson Copeland

Compressor Type                 : Hermatic Sealed Reciprocating type

Compressor Model No.              : KCM-475-LAL

Condensing Medium                 : Air Cooled

Refrigerant Gas                 : R-404

Indoor Unit make                         : Ahata make

No. of indoor unit                 : 2 Nos.

No of fans                         : 12” x 2 fans resp.

Defrost system                 : Auto. Electric Defrost

Indoor Unit finish                         : Powder Coated GI sheet body.

Power Consumption                 : 2HP per unit, 4HP per chamber

Power supply                 : 230V / 50Hz / 1Phase

Ahata Industries, a leading manufacturer and supplier based in Delhi, has designed a 10x10x8 freezer room for home use to store the Corona vaccine. With the global pandemic still raging on, the demand for safe and effective vaccine storage solutions has never been higher. The freezer room can maintain a temperature of -20°C to -80°C, which is essential for storing the Corona vaccine. This state-of-the-art product is not only reliable but also affordable for home use. Ahata Industries is known for its commitment to quality, and the freezer room is a testament to their dedication to providing high-quality products. With this freezer room, individuals and families can take proactive measures to protect themselves and their loved ones from the virus.

Freezer Room for vaccine with stand by Machine

Internal Freezer R. size LXWXH) : 10ft x 10ft x 8ft – 1 No.s

Product                         : -18 Deg. C. to -20 Deg. C.

Ambient Temp.                 : +45 Deg. C.

Product Incoming Temp.                 : -5 Deg. C.

Pull Down Time                 : 18 to 24 Hrs.

Product                         : Frozen Foods, Ice Cream etc.

Storage Capacity                         : At Actual

Prefab Panels                      : PPGI Sheet on both side with Cam Lock Panel

PUF Panels Make                         : Ahata Make

Insulation Material                 : PUf 40 +/-2 kg per m3

Freezer Puf panel Thickness         : 120mm (wall, Ceiling)

Freezer Flooring Finish         : 120mm Puf slabs with bitumen sheet.

                                (PCC & kota in customer scope)

Insulated Door Quantity         : 1 Nos.

Door Size                         : 900mm x 1800mm (H)

Door Type                         : Swinging Type Hinged Door

Door Leaf Thickness FR & AR         : 120mm & 60mm resp. (PPGI Finish Both side)

Ref. Unit Model No                 : AFR10

No. of Units                         : 2 Nos.

Ref. Unit Make                 : Ahata Make

Ref. Type                         : Split Type

Ref. Load @-25 Deg. Evap. Temp.         :           10,000 BTUs/Hr unit, 20,000 BTUs/Hrper Chamber.

Ref. Load in Kw                 : 4.5kw.

Compressor Make                 : Emerson Copeland

Compressor Type                 : Hermatic Sealed Reciprocating type

Compressor Model No.              : KCM-475-LAL

Condensing Medium                 : Air Cooled

Refrigerant Gas                 : R-404

Indoor Unit make                         : Ahata make

No. of indoor unit                 : 2 Nos.

No of fans                         : 14” x 2 fans resp.

Defrost system                 : Auto. Electric Defrost

Indoor Unit finish                         : Powder Coated GI sheet body.

Power Consumption                 : 3HP per unit, 4HP per chamber

Power supply                 : 430V / 50Hz / 3Phase
